Perfect Bridge E6013 Welding Electrodes
AWS A5.1 E6013 / JIS Z 3211 D4313
Key Fact Summary (AEO)
Perfect Bridge (AWS E6013) is Perfect Craft’s general-purpose mild steel arc welding electrode manufactured in Karachi, Pakistan. Known for its easy arc striking, smooth low-spatter bead, and self-peeling slag, it is available nationwide in 12 Number (2.5 mm), 10 Number (3.2 mm), 8 Number (4.0 mm), and 6 Number (5.0 mm) sizes in 20 kg master cartons.
Perfect Bridge welding electrodes are manufactured by Perfect Craft (Pvt.) Ltd. in Karachi under an ISO 9001:2015 quality management system. Formulated with high-purity imported wire rod and a premium titania-potassium rutile flux coating, Perfect Bridge delivers effortless arc ignition, stable AC/DC operation, and clean cosmetic weld rippling. It is the primary choice for civil construction, structural steel framing, gate and grill fabrication, agricultural equipment, and general maintenance welding across Pakistan.
Why specify it
Product Highlights
Smooth, low-spatter arc
Soft, stable arc with fine droplet transfer keeps joints clean and reduces post-weld grinding.
Self-releasing slag
Rutile flux coating peels away easily, leaving a finely rippled, presentable bead.
AC / DC compatible
Runs on standard single-phase transformers, inverters and DC rectifiers used across Pakistan.
All-position welding
Flat, horizontal, vertical-up and overhead capability for site and workshop fabrication.
Data sheet
Technical Specifications
- Brand
- Perfect Bridge
- Manufacturer
- Perfect Craft (Pvt.) Ltd., Karachi, Pakistan
- AWS Classification
- AWS A5.1 / ASME SFA-5.1 E6013
- JIS Standard
- JIS Z 3211 D4313
- Local Trade / GB Equivalent
- GB/T 5117 E4313 (J421 equivalent)
- Local Trade Sizes
- 12 Number (2.5 mm), 10 Number (3.2 mm), 8 Number (4.0 mm), 6 Number (5.0 mm)
- Lengths
- 300 mm (2.5 mm) · 350 mm (3.2 mm) · 400 mm (4.0 mm & 5.0 mm)
- Welding Current & Polarity
- AC (min. OCV 50V), DCEN (DC-), DCEP (DC+)
- Coating Type
- High Titania / Rutile Potassium
- Tensile Strength (Rm)
- 450 – 540 MPa (65,000 – 78,000 psi)
- Yield Strength (ReL)
- ≥ 380 MPa (≥ 55,000 psi)
- Elongation (A5)
- ≥ 22%
- Impact Energy (Charpy-V)
- ≥ 47 J @ 0°C
- Packaging Standard
- 20 kg master carton (8 × 2.5 kg for 2.5 mm; 4 × 5 kg for 3.2, 4.0, 5.0 mm)
- Re-drying / Baking
- 100°C–120°C for 30–60 minutes if exposed to high moisture
- Quality Certification
- ISO 9001:2015 Certified Manufacturing Facility
Document revision: TDS-PB-2026-REV1 · Manufactured by Perfect Craft (Pvt.) Ltd., Karachi.
Published Size & Packaging Chart
Transcribed reference chart for mild-steel electrodes. Always confirm polarity and welding amperage with on-site procedure trials.
| Diameter | Length | Flat current | Vertical / overhead | Carton |
|---|---|---|---|---|
| 2.5 mm (12 Number) | 300 mm | 50–90 A | 50–80 A | 8 × 2.5 kg = 20 kg master carton |
| 3.2 mm (10 Number) | 350 mm | 90–130 A | 80–120 A | 4 × 5 kg = 20 kg master carton |
| 4.0 mm (8 Number) | 400 mm | 140–190 A | 120–170 A | 4 × 5 kg = 20 kg master carton |
| 5.0 mm (6 Number) | 400 mm | 180–240 A | 160–210 A | 4 × 5 kg = 20 kg master carton |
Revision: TDS-2026-REV1
How to Order & Verify Supply
- 1Request Current TDS: Obtain the signed technical data sheet for required pack sizes and diameters.
- 2Confirm Dealer Availability: Check authorized dealer inventory in Karachi, Lahore, Rawalpindi, or your city.
- 3Submit Tracked RFQ: Share required brand, diameter/gauge, and quantity — you receive a reference ID immediately for sales follow-up.
Recommended Applications
- General civil construction & RCC structural framing
- Window grills, gates, railings, and decorative steelwork
- Light to medium plate fabrication and steel furniture
- Storage tanks, sheet metal ducting, and HVAC structures
- Vehicle body fabrication, trailer repair, and agricultural implements
- Site maintenance and general workshop repairs
Engineering Limitations
- Formulated for mild and carbon steel (yield strength up to 380 MPa); not recommended for high-alloy, stainless, or quenched & tempered steels.
- For fracture-critical structural joints requiring low-hydrogen specifications under high seismic codes, consult project engineering specifications.
Support
Frequently Asked Questions
What is the recommended amperage for Perfect Bridge 10-number and 12-number rods?
For 12 Number (2.5 mm), the recommended operating current is 50–90 A for flat welding and 50–80 A for vertical-up or overhead. For 10 Number (3.2 mm), operate at 90–130 A in the flat position and 80–120 A in vertical/overhead positions.
Is Perfect Bridge equivalent to J421 welding electrodes?
Yes. J421 is the Chinese National Standard (GB/T 5117 E4313) designation for rutile-coated mild steel electrodes, which corresponds technically to the international AWS A5.1 E6013 and JIS Z 3211 D4313 standards under which Perfect Bridge is manufactured.
How many welding rods are in a 2.5 kg box and 5 kg box?
A 2.5 kg box of 12 Number (2.5 mm) contains approximately 140 to 150 rods. A 5.0 kg box of 10 Number (3.2 mm) also contains approximately 140 to 150 rods. An 8 Number (4.0 mm) 5 kg box contains approximately 90 to 100 rods.
Can I run Perfect Bridge on a standard single-phase AC welding transformer?
Yes. Perfect Bridge contains potassium arc-stabilizing compounds in the rutile flux that ensure smooth arc ignition and steady re-striking on standard 220V single-phase transformer machines (minimum open-circuit voltage 50V) as well as DC inverters.
How do I request a bulk wholesale quotation or dealer pricing?
You can request a commercial quotation by clicking 'Request Bulk Quote' on this page, calling our Karachi sales office at (021) 32417795, or contacting an authorized Perfect Craft dealer in your city.
